The Hivi S5N Low Midrange Speaker is a high-power speaker that offers exceptional sound quality for a wide range of applications. With its technical parameters and unique design, this speaker is the perfect choice for music lovers and audiophiles alike.
Starting with its rated impedance, the S5N speaker boasts an 8Ω rating, ensuring that it can handle a wide range of frequencies and deliver powerful sound output. The resonance frequency of this speaker is 49Hz, which means that it is able to produce powerful low-mid range sounds with exceptional clarity.
With a rated power of 35W and a maximum power of 70W, the S5N speaker is able to handle high-powered audio inputs with ease. Its sensitivity (2.83v/1m) is 87dB, which ensures that it can deliver rich, dynamic sound even at low volumes. The speaker's weight of 2kg is designed to be compact and lightweight, making it easy to install in a wide range of cabinets.
The voice coil diameter of this speaker is 25mm, with a DC resistance of 6.5Ω and a voice coil roll width of 10.4mm. The voice coil wire is made from high-temperature resistant SV wire, while the voice coil frame is constructed from high-temperature resistant Kapton. This makes the S5N speaker extremely durable and resistant to damage, even under extreme conditions.
The magnetic circuit type used in the S5N speaker is a shielded antimagnetic magnetic circuit, which helps to reduce electromagnetic interference and ensure optimal sound quality. The magnet material used in this speaker is high-performance ferrite, with a force coefficient (BL value) of 7.7N/A. The magnetic gap height is 5.0mm, with a maximum linear displacement of 2.7mm.
The compliance of the S5N speaker is 1000uM/N, with a mechanical Q value of 6.17- and an electric Q value of 0.35-. The total Q value of this speaker is 0.34-, while the vibration mass is 10.5g. The equivalent volume of this speaker is 8.9L, making it ideal for use in a wide range of cabinets.
The cabinet type used in the S5N speaker is a lead phase, with a recommended net volume of 6L. The tuning frequency of the phase guide tube is 52Hz, while the cabinet is in free field-3db frequency is 49Hz.
In conclusion, the Hivi S5N Low Midrange Speaker is a high-quality, high-power speaker that offers exceptional sound quality and durability. With its technical parameters and unique design, this speaker is the perfect choice for music lovers and audiophiles alike.
